Application Industry

Root crusher can process wood with nails, wooden pallets, waste templates on construction sites, wooden brackets, tree stumps, waste furniture, branches, wood, template waste, house demolition waste, doors, and windows, etc. for crushing.

Product introduction

Product introduction
  • Introduction
  • Feature
This equipment can be used to crush large-diameter materials such as tree roots and waste furniture. It can also be used to crush baled straw, which is more suitable.It is used for crushing small-diameter wood and board scraps. It has the advantages of rapid feeding and high efficiency
  • Compact structure and simple design make the wood crusher easy to clean and maintain.
  • High yield and stable working performance ensure continuous running.
  • It's can crush logs, root,branches, shrubs, bamboo, straw, bark, wheat stalks, and other wood material into sawdust or sawdust. Raw material has a better crushing effect.
mature project design, and complete
after-sales service process.

+86-15093222637

Consult now

Working principle

  • 1. The feeding part:

    the feed hopper is also driven by the diesel engine to rotate slowly. The material is put into the hopper through the grab machine. Transfer the material evenly to the rotor.

  • 2. The crush part:

    he disc-type tree root crusher is driven by a diesel engine to run the rotor at high speed.Put the tree roots and other materials into the crushing chamber,the volume of the roots and stumps will shrink after being collided and cut by the blade,and the crushed materials will also fall to the bottom screen due to their own gravity and other factors.After filtering, they meet the requirements. The materials that do not meet the requirements will be filtered out, and those that do not meet the requirements will continue to be crushed.

Working principle

Performance parameter

Model Power（kw） Capacity（t/h) Rotating speed(r/min) Number of blades(piece) Dimensions
MT2600 90 6-10 960 4 4000*2600*3250
MT3000 132 10-15 960 6/18 4500*3000*3250
MT3600 185 20-25 960 6/24 5300*3600*3550
MTZ3600 220 30-35 960 10/36 6300*3600*3500
MTGT3000 340 10-15 980 6/18 8200*3000*3500
MTGT3600 420 20-25 980 6/24 8500*3600*3500
MTGT3600 530 30-35 980 10/36 8500*3600*3500

*Note： Any change of technical data shall not be advised additionally.

Production case

Wood crushing
